Pickit
Pickit M bin picking TM Kit

Categories: ,

Pickit is a 3D vision system for random and semi-structured bin picking for a range of applications. We make it easy to run in production:

  • Experience an easy setup with built-in support
  •  Make use of our application specific engines for billets and metal cylinders / bags / sheet metal. Next to that Pickit offers a flexible toolbox for other applications.
  • Optionally order services to develop a reliable and production-ready cell fast, covering POC, gripper design, robot-camera positions, re-pick stations.

Features
Application attributes

  • Typical object dimensions: 100 x 100 x 10 mm
  • Typical bin dimensions: 600 x 400 x 300 mm
  • Typical application cycle time: 10 sec

Software features

  • Full 3D orientation, pick and place accurately
  • Collision avoidance and smart motions for emptying your bins
  • Instant teach in of the parts from camera or CAD.

Camera features

  • High-resolution
  • Captures color and depth information
  • Robot mounted or stationary

Support

  • Built-in support – capture and share your results in one click to get support.
  • Guaranteed response within 24H to support questions.
Specification
3D measurement method Structured light
Image processing speed 10 Hz (100ms snapshots)
3D Camera accuracy <3 mm
Picking accuracy* 10mm
3D Camera repeatability 1mm
3D camera weight 1030 g
3D camera connection to PC M12-8 (USB) – USB3
PC connection to robot TCP/IP over Ethernet
Power supply USB3 5 VDC
Temperature 5°C to 40°C
Humidity ∼95% @ 40℃ (non-condensing)
IP rating IP65
Vibrations Operating, 2 Grms, 5-500 Hz, 3 axes
Conforms to CE, FCC

*Average accuracy from the real production environment

Compatibility
HW: HW 1.0 and above
SW: SW 1.72 and above

Product Link
https://www.pickit3d.com/pick-it-works-with-your-robots/techman

Pickit 3D purchase contact info.

Availability: Global

Please contact with Pickit 3D Official Website

Please notice the seller it’s “TM Plug&Play” when you purchase the package.
